The Jetson family of products offers solutions to meet AI computing needs of intelligent machines across the board, including IoT, autonomous drones, and intelligent robots. Jetson TX2 is the fastest, most power-efficient AI computing device. The latest addition to the industry-leading Jetson platform, this 7.5-watt supercomputer on a module brings true AI computing at the edge. It's built around an NVIDIA Pascal™-family GPU and loaded with 8 GB of memory and 59.7 GB/s of memory bandwidth. Jetson TX1 is the word's first supercomputer on a module. This is a powerful, highly efficient solution that's ideal for building AI enabled products. It's built around an NVIDIA Maxwell™-family GPU and features 4 GB of memory and 25.6 GB/s of memory bandwidth.


Jetson TX2 Jetson TX1
GPU NVIDIA Pascal™, 256 CUDA cores NVIDIA Maxwell ™, 256 CUDA cores
CPU HMP Dual Denver 2/2 MB L2 + Quad ARM® A57/2 MB L2 Quad ARM® A57/2 MB L2
VIDEO 4K x 2K 60 Hz Encode (HEVC) 4K x 2K 60 Hz Decode (12-Bit Support) 4K x 2K 30 Hz Encode (HEVC) 4K x 2K 60 Hz Decode (10-Bit Support)
MEMORY 8 GB 128 bit LPDDR4 59.7 GB/s 4 GB 64 bit LPDDR4 25.6 GB/s
DISPLAY 2x DSI, 2x DP 1.2 / HDMI 2.0 / eDP 1.4 2x DSI, 1x eDP 1.4 / DP 1.2 / HDMI
CSI Up to 6 Cameras (2 Lane) CSI2 D-PHY 1.2 (2.5 Gbps/Lane) Up to 6 Cameras (2 Lane) CSI2 D-PHY 1.1 (1.5 Gbps/Lane)
PCIE Gen 2 | 1x4 + 1x1 OR 2x1 + 1x2 Gen 2 | 1x4 + 1x1
DATA STORAGE 32 GB eMMC, SDIO, SATA 16 GB eMMC, SDIO, SATA
OTHER CAN, UART, SPI, I2C, I2S, GPIOs UART, SPI, I2C, I2S, GPIOs
USB USB 3.0 + USB 2.0 USB 3.0 + USB 2.0
CONNECTIVITY 1 Gigabit Ethernet, 802.11ac WLAN, Bluetooth 1 Gigabit Ethernet, 802.11ac WLAN, Bluetooth
MECHANICAL 50 mm x 87 mm (400-Pin Compatible Board-to-Board Connector) 50 mm x 87 mm (400-Pin Compatible Board-to-Board Connector)



No matter where you are in the design process, we make it easy to find the right hardware documents you need. Our download center has the latest versions of hardware documentation for immediate download, and new updates are added on a regular basis. Follow the links below to get started.

Download the latest Jetson TX2, Jetson TX1, Jetson TK1 hardware docs from the download center*.

*Please Note: Some documents require that you are a member of the NVIDIA Developer Program for download. If you are not already a member, join the Developer Program now.
