Detailed Description
Structure containing ISP Stats information.
Definition at line 159 of file NvSIPLControlAutoDef.hpp.
Data Fields | |
| const NvSiplISPLocalAvgClipStatsData * | lacData [2] |
| Holds pointers to 2 LAC stats data. More... | |
| const NvSiplISPLocalAvgClipStats * | lacSettings [2] |
| Holds pointers to 2 LAC stats settings. More... | |
| const NvSiplISPHistogramStatsData * | histData [2] |
| Holds pointers to 2 Histogram stats data. More... | |
| const NvSiplISPHistogramStats * | histSettings [2] |
| Holds pointers to 2 Histogram stats settings. More... | |
| const NvSiplISPFlickerBandStatsData * | fbStatsData |
| Holds pointer to Flicker Band stats data. More... | |
| const NvSiplISPFlickerBandStats * | fbStatsSettings |
| Holds pointer to Flicker Band stats settings. More... | |
Field Documentation
◆ fbStatsData
| const NvSiplISPFlickerBandStatsData* nvsipl::SiplControlIspStatsInfo::fbStatsData |
Holds pointer to Flicker Band stats data.
This variable is not supported in SIPL Control Auto.
Definition at line 180 of file NvSIPLControlAutoDef.hpp.
◆ fbStatsSettings
| const NvSiplISPFlickerBandStats* nvsipl::SiplControlIspStatsInfo::fbStatsSettings |
Holds pointer to Flicker Band stats settings.
This variable is not supported in SIPL Control Auto.
Definition at line 185 of file NvSIPLControlAutoDef.hpp.
◆ histData
| const NvSiplISPHistogramStatsData* nvsipl::SiplControlIspStatsInfo::histData[2] |
Holds pointers to 2 Histogram stats data.
Definition at line 171 of file NvSIPLControlAutoDef.hpp.
◆ histSettings
| const NvSiplISPHistogramStats* nvsipl::SiplControlIspStatsInfo::histSettings[2] |
Holds pointers to 2 Histogram stats settings.
Definition at line 175 of file NvSIPLControlAutoDef.hpp.
◆ lacData
| const NvSiplISPLocalAvgClipStatsData* nvsipl::SiplControlIspStatsInfo::lacData[2] |
Holds pointers to 2 LAC stats data.
Definition at line 163 of file NvSIPLControlAutoDef.hpp.
◆ lacSettings
| const NvSiplISPLocalAvgClipStats* nvsipl::SiplControlIspStatsInfo::lacSettings[2] |
Holds pointers to 2 LAC stats settings.
Definition at line 167 of file NvSIPLControlAutoDef.hpp.
The documentation for this struct was generated from the following file:
