Detailed Description
Holds controls for local average and clip statistics (LAC Stats).
Definition at line 487 of file NvSIPLISPStat.hpp.
Data Fields | |
| NvSiplBool | enable |
| Holds a Boolean to enable the local average and clip statistics block. More... | |
| float_t | min [NVSIPL_ISP_MAX_COLOR_COMPONENT] |
| Holds minimum value of pixels in RGGB/RCCB/RCCC order. More... | |
| float_t | max [NVSIPL_ISP_MAX_COLOR_COMPONENT] |
| Holds maximum value of pixels in RGGB/RCCB/RCCC order. More... | |
| NvSiplBool | roiEnable [NVSIPL_ISP_MAX_LAC_ROI] |
| Holds a Boolean to enable an individual region of interest. More... | |
| NvSiplISPStatisticsWindows | windows [NVSIPL_ISP_MAX_LAC_ROI] |
| Holds local average and clip windows for each region of interest. More... | |
| NvSiplBool | ellipticalMaskEnable [NVSIPL_ISP_MAX_LAC_ROI] |
| Holds a Boolean to enable an elliptical mask for excluding pixels outside a specified area for each region of interest. More... | |
| NvSiplISPEllipse | ellipticalMask |
| Holds an elliptical mask for excluding pixels outside specified area. More... | |
Field Documentation
◆ ellipticalMask
| NvSiplISPEllipse nvsipl::NvSiplISPLocalAvgClipStats::ellipticalMask |
Holds an elliptical mask for excluding pixels outside specified area.
Coordinates of the image top left and bottom right points are (0, 0) and (width, height), respectively.
Definition at line 521 of file NvSIPLISPStat.hpp.
◆ ellipticalMaskEnable
| NvSiplBool nvsipl::NvSiplISPLocalAvgClipStats::ellipticalMaskEnable[NVSIPL_ISP_MAX_LAC_ROI] |
Holds a Boolean to enable an elliptical mask for excluding pixels outside a specified area for each region of interest.
Definition at line 514 of file NvSIPLISPStat.hpp.
◆ enable
| NvSiplBool nvsipl::NvSiplISPLocalAvgClipStats::enable |
Holds a Boolean to enable the local average and clip statistics block.
Definition at line 491 of file NvSIPLISPStat.hpp.
◆ max
| float_t nvsipl::NvSiplISPLocalAvgClipStats::max[NVSIPL_ISP_MAX_COLOR_COMPONENT] |
Holds maximum value of pixels in RGGB/RCCB/RCCC order.
Valid Range: [0.0, 1.0], max >= min
Definition at line 501 of file NvSIPLISPStat.hpp.
◆ min
| float_t nvsipl::NvSiplISPLocalAvgClipStats::min[NVSIPL_ISP_MAX_COLOR_COMPONENT] |
Holds minimum value of pixels in RGGB/RCCB/RCCC order.
Valid Range: [0.0, 1.0]
Definition at line 496 of file NvSIPLISPStat.hpp.
◆ roiEnable
| NvSiplBool nvsipl::NvSiplISPLocalAvgClipStats::roiEnable[NVSIPL_ISP_MAX_LAC_ROI] |
Holds a Boolean to enable an individual region of interest.
Definition at line 505 of file NvSIPLISPStat.hpp.
◆ windows
| NvSiplISPStatisticsWindows nvsipl::NvSiplISPLocalAvgClipStats::windows[NVSIPL_ISP_MAX_LAC_ROI] |
Holds local average and clip windows for each region of interest.
Definition at line 509 of file NvSIPLISPStat.hpp.
The documentation for this struct was generated from the following file:
