Detailed Description
Parameters for histogram estimators.
Definition at line 229 of file CalibrationTypesExtra.h.
Data Fields | |
| float32_t | correctionRange |
| Min/Max range for correction values [-correctionRange, correctionRange] around zero (signal units) More... | |
| float32_t | correctionAccuracy |
| The distance between histogram bins (signal units) More... | |
| float32_t | acceptanceMinSampleCount |
| The minimum number of samples in the histogram peak bin required for acceptance. More... | |
| float32_t | acceptanceNoiseSampleCount |
| The number of samples in a bin that will be discarded as noise. More... | |
| float32_t | acceptanceSigma |
| The width of the envelope function used to determine acceptance (signal units) More... | |
| float32_t | failureOutlierRange |
| Samples outside [-failureOutlierRange, failureOutlierRange] will be considered as outliers (signal units) More... | |
| uint32_t | failureMaxOutlierCount |
| The maximum number of recent outliers not in the histogram limits that will trigger a failure of the estimation. More... | |
| float32_t | smoothingSigma |
| Smoothing sigma for histogram low-pass filtering (signal units) More... | |
| float32_t | decayRate |
| Decay rate for the long term decay histogram (unitless) More... | |
| float32_t | shortTermScale |
| Factor applied to long-term decay rate to obtain short term decay rate (unitless, should be < 1, FastAcceptanceRejectionEstimator only) More... | |
| float32_t | amplitudeScaleFactor |
| Factor for all envelopes used to scale envelope max value relative to histogram max value (unitless, should be > 1, FastAcceptanceRejectionEstimator only) More... | |
| float32_t | shortSigmaFactor |
| Factor applied to acceptanceSigma for short-term envelope (unitless, FastAcceptanceRejectionEstimator only) More... | |
| float32_t | rejectionSigmaFactor |
| Factor applied to acceptanceSigma for rejection envelope (unitless, FastAcceptanceRejectionEstimator only) More... | |
| float32_t | fastAcceptanceMinSampleCount |
| The minimum number of samples in the short-term histogram peak bin to consider it for fast-acceptance (FastAcceptanceRejectionEstimator only) More... | |
| float32_t | fastAcceptanceThreshold |
| Fast acceptance +/- value envelope around reference that is being fast-accepted, 0 or negative to disable fast acceptance (signal units, FastAcceptanceRejectionEstimator only) More... | |
| float32_t | baseErrorBound |
| When estimating the error bound of the signal, add this as a base value to represent unmodeled/general uncertainty. More... | |
| dwFastRejectionEvaluationParameters | fastRejectionEvaluationParameters |
| Fast rejection evaluation parameters. More... | |
| dwFastRejectionReactionParameters | fastRejectionReactionParameters |
| Fast rejection reaction parameters. More... | |
Field Documentation
◆ acceptanceMinSampleCount
| float32_t dwCalibrationHistogramEstimatorParameters::acceptanceMinSampleCount |
The minimum number of samples in the histogram peak bin required for acceptance.
Definition at line 238 of file CalibrationTypesExtra.h.
◆ acceptanceNoiseSampleCount
| float32_t dwCalibrationHistogramEstimatorParameters::acceptanceNoiseSampleCount |
The number of samples in a bin that will be discarded as noise.
Definition at line 241 of file CalibrationTypesExtra.h.
◆ acceptanceSigma
| float32_t dwCalibrationHistogramEstimatorParameters::acceptanceSigma |
The width of the envelope function used to determine acceptance (signal units)
Definition at line 244 of file CalibrationTypesExtra.h.
◆ amplitudeScaleFactor
| float32_t dwCalibrationHistogramEstimatorParameters::amplitudeScaleFactor |
Factor for all envelopes used to scale envelope max value relative to histogram max value (unitless, should be > 1, FastAcceptanceRejectionEstimator only)
Definition at line 262 of file CalibrationTypesExtra.h.
◆ baseErrorBound
| float32_t dwCalibrationHistogramEstimatorParameters::baseErrorBound |
When estimating the error bound of the signal, add this as a base value to represent unmodeled/general uncertainty.
Definition at line 277 of file CalibrationTypesExtra.h.
◆ correctionAccuracy
| float32_t dwCalibrationHistogramEstimatorParameters::correctionAccuracy |
The distance between histogram bins (signal units)
Definition at line 235 of file CalibrationTypesExtra.h.
◆ correctionRange
| float32_t dwCalibrationHistogramEstimatorParameters::correctionRange |
Min/Max range for correction values [-correctionRange, correctionRange] around zero (signal units)
Definition at line 232 of file CalibrationTypesExtra.h.
◆ decayRate
| float32_t dwCalibrationHistogramEstimatorParameters::decayRate |
Decay rate for the long term decay histogram (unitless)
Definition at line 256 of file CalibrationTypesExtra.h.
◆ failureMaxOutlierCount
| uint32_t dwCalibrationHistogramEstimatorParameters::failureMaxOutlierCount |
The maximum number of recent outliers not in the histogram limits that will trigger a failure of the estimation.
Definition at line 250 of file CalibrationTypesExtra.h.
◆ failureOutlierRange
| float32_t dwCalibrationHistogramEstimatorParameters::failureOutlierRange |
Samples outside [-failureOutlierRange, failureOutlierRange] will be considered as outliers (signal units)
Definition at line 247 of file CalibrationTypesExtra.h.
◆ fastAcceptanceMinSampleCount
| float32_t dwCalibrationHistogramEstimatorParameters::fastAcceptanceMinSampleCount |
The minimum number of samples in the short-term histogram peak bin to consider it for fast-acceptance (FastAcceptanceRejectionEstimator only)
Definition at line 271 of file CalibrationTypesExtra.h.
◆ fastAcceptanceThreshold
| float32_t dwCalibrationHistogramEstimatorParameters::fastAcceptanceThreshold |
Fast acceptance +/- value envelope around reference that is being fast-accepted, 0 or negative to disable fast acceptance (signal units, FastAcceptanceRejectionEstimator only)
Definition at line 274 of file CalibrationTypesExtra.h.
◆ fastRejectionEvaluationParameters
| dwFastRejectionEvaluationParameters dwCalibrationHistogramEstimatorParameters::fastRejectionEvaluationParameters |
Fast rejection evaluation parameters.
Definition at line 280 of file CalibrationTypesExtra.h.
◆ fastRejectionReactionParameters
| dwFastRejectionReactionParameters dwCalibrationHistogramEstimatorParameters::fastRejectionReactionParameters |
Fast rejection reaction parameters.
Definition at line 283 of file CalibrationTypesExtra.h.
◆ rejectionSigmaFactor
| float32_t dwCalibrationHistogramEstimatorParameters::rejectionSigmaFactor |
Factor applied to acceptanceSigma for rejection envelope (unitless, FastAcceptanceRejectionEstimator only)
Definition at line 268 of file CalibrationTypesExtra.h.
◆ shortSigmaFactor
| float32_t dwCalibrationHistogramEstimatorParameters::shortSigmaFactor |
Factor applied to acceptanceSigma for short-term envelope (unitless, FastAcceptanceRejectionEstimator only)
Definition at line 265 of file CalibrationTypesExtra.h.
◆ shortTermScale
| float32_t dwCalibrationHistogramEstimatorParameters::shortTermScale |
Factor applied to long-term decay rate to obtain short term decay rate (unitless, should be < 1, FastAcceptanceRejectionEstimator only)
Definition at line 259 of file CalibrationTypesExtra.h.
◆ smoothingSigma
| float32_t dwCalibrationHistogramEstimatorParameters::smoothingSigma |
Smoothing sigma for histogram low-pass filtering (signal units)
Definition at line 253 of file CalibrationTypesExtra.h.
The documentation for this struct was generated from the following file:
