Detailed Description
Holds controls for histogram statistics (HIST Stats).
Definition at line 376 of file NvSIPLISPStat.hpp.
Data Fields | |
| NvSiplBool | enable |
| Holds a Boolean to enable histogram statistics block. More... | |
| float_t | offset |
| Holds offset to be applied to input data prior to bin mapping. More... | |
| uint8_t | knees [NVSIPL_ISP_HIST_KNEE_POINTS] |
| Holds bin index specifying different zones in the histogram. More... | |
| uint8_t | ranges [NVSIPL_ISP_HIST_KNEE_POINTS] |
| Holds \(log_2\) range of the pixel values to be considered for each zone. More... | |
| NvSiplRect | rectangularMask |
| Holds a rectangular mask for excluding pixels outside a specified area. More... | |
| NvSiplBool | ellipticalMaskEnable |
| Holds a Boolean to enable an elliptical mask for excluding pixels outside a specified area. More... | |
| NvSiplISPEllipse | ellipticalMask |
| Holds an elliptical mask for excluding pixels outside a specified area. More... | |
| NvSiplBool | ellipticalWeightEnable |
| Holds a Boolean to enable elliptical weighting of pixels based on spatial location. More... | |
| NvSiplISPRadialTF | radialTF |
| Holds a radial transfer function for elliptical weight. More... | |
Field Documentation
◆ ellipticalMask
| NvSiplISPEllipse nvsipl::NvSiplISPHistogramStats::ellipticalMask |
Holds an elliptical mask for excluding pixels outside a specified area.
Coordinates of the image top left and bottom right points are (0, 0) and (width, height), respectively.
- Supported values for X coordinate of the center: [0, input width]
- Supported values for Y coordinate of the center: [0, input height]
- Supported values for horizontal axis: [16, 2 x input width]
- Supported values for vertical axis: [16, 2 x input height]
- Supported values for angle: [0.0, 360.0]
Definition at line 431 of file NvSIPLISPStat.hpp.
◆ ellipticalMaskEnable
| NvSiplBool nvsipl::NvSiplISPHistogramStats::ellipticalMaskEnable |
Holds a Boolean to enable an elliptical mask for excluding pixels outside a specified area.
Definition at line 418 of file NvSIPLISPStat.hpp.
◆ ellipticalWeightEnable
| NvSiplBool nvsipl::NvSiplISPHistogramStats::ellipticalWeightEnable |
Holds a Boolean to enable elliptical weighting of pixels based on spatial location.
This can be used to compensate for lens shading when the histogram is measured before lens shading correction.
Definition at line 437 of file NvSIPLISPStat.hpp.
◆ enable
| NvSiplBool nvsipl::NvSiplISPHistogramStats::enable |
Holds a Boolean to enable histogram statistics block.
Definition at line 380 of file NvSIPLISPStat.hpp.
◆ knees
| uint8_t nvsipl::NvSiplISPHistogramStats::knees[NVSIPL_ISP_HIST_KNEE_POINTS] |
Holds bin index specifying different zones in the histogram.
Each zone can have a different number of bins.
- Supported values: [1, 255]
Definition at line 391 of file NvSIPLISPStat.hpp.
◆ offset
| float_t nvsipl::NvSiplISPHistogramStats::offset |
Holds offset to be applied to input data prior to bin mapping.
- Supported values: [-2.0, 2.0]
Definition at line 385 of file NvSIPLISPStat.hpp.
◆ radialTF
| NvSiplISPRadialTF nvsipl::NvSiplISPHistogramStats::radialTF |
Holds a radial transfer function for elliptical weight.
- Supported values: Check the declaration of NvSiplISPRadialTF.
Definition at line 442 of file NvSIPLISPStat.hpp.
◆ ranges
| uint8_t nvsipl::NvSiplISPHistogramStats::ranges[NVSIPL_ISP_HIST_KNEE_POINTS] |
Holds \(log_2\) range of the pixel values to be considered for each zone.
The whole pixel range is divided into NVSIPL_ISP_HIST_KNEE_POINTS zones.
- Supported values: [0, 21]
Definition at line 398 of file NvSIPLISPStat.hpp.
◆ rectangularMask
| NvSiplRect nvsipl::NvSiplISPHistogramStats::rectangularMask |
Holds a rectangular mask for excluding pixels outside a specified area.
The coordinates of image top left and bottom right points are (0, 0) and (width, height), respectively. A rectangle ((right > left) && (bottom > top)), or must be ((0,0), (0,0)) to disable the rectangular mask.
The rectangle settings(x0, y0, x1, y1) must follow the constraints listed below:
- (x0 >= 0) and (y0 >= 0)
- x0 and x1 should be even
- (x1 <= image width) and (y1 <= image height)
- rectangle width(x1 - x0) >= 2 and height(y1 - y0) >= 2
Definition at line 413 of file NvSIPLISPStat.hpp.
The documentation for this struct was generated from the following file:
