Detailed Description
Defines information for the camera module.
A camera module is a physical grouping of a serializer, image sensor(s), and associated EEPROM(s).
Definition at line 217 of file NvSIPLDeviceBlockInfo.hpp.
Data Fields | |
| std::string | name = "" |
| Holds the name of the camera module, for example, "SF3324". More... | |
| std::string | description = "" |
| Holds the description of the camera module. More... | |
| uint32_t | linkIndex = UINT32_MAX |
| Holds the index of the deserializer link to which this module is connected. More... | |
| SerInfo | serInfo |
| Holds the SerInfo of the serializer. More... | |
| bool | isEEPROMSupported = false |
| Holds EEPROM support. More... | |
| EEPROMInfo | eepromInfo |
| Holds the information about EEPROM device in a camera module. More... | |
| SensorInfo | sensorInfo |
| Holds the information about the sensor in a camera module. More... | |
Field Documentation
◆ description
| std::string nvsipl::CameraModuleInfo::description = "" |
Holds the description of the camera module.
Definition at line 223 of file NvSIPLDeviceBlockInfo.hpp.
◆ eepromInfo
| EEPROMInfo nvsipl::CameraModuleInfo::eepromInfo |
Holds the information about EEPROM device in a camera module.
Definition at line 234 of file NvSIPLDeviceBlockInfo.hpp.
◆ isEEPROMSupported
| bool nvsipl::CameraModuleInfo::isEEPROMSupported = false |
Holds EEPROM support.
Definition at line 231 of file NvSIPLDeviceBlockInfo.hpp.
◆ linkIndex
| uint32_t nvsipl::CameraModuleInfo::linkIndex = UINT32_MAX |
Holds the index of the deserializer link to which this module is connected.
Definition at line 227 of file NvSIPLDeviceBlockInfo.hpp.
◆ name
| std::string nvsipl::CameraModuleInfo::name = "" |
Holds the name of the camera module, for example, "SF3324".
Definition at line 220 of file NvSIPLDeviceBlockInfo.hpp.
◆ sensorInfo
| SensorInfo nvsipl::CameraModuleInfo::sensorInfo |
Holds the information about the sensor in a camera module.
Definition at line 236 of file NvSIPLDeviceBlockInfo.hpp.
◆ serInfo
| SerInfo nvsipl::CameraModuleInfo::serInfo |
Holds the SerInfo of the serializer.
Definition at line 229 of file NvSIPLDeviceBlockInfo.hpp.
The documentation for this struct was generated from the following file:
