Detailed Description
Defines the camera pipeline configuration.
Definition at line 400 of file NvSIPLPipelineMgr.hpp.
Data Fields | |
| bool | captureOutputRequested {false} |
true if the client wants capture output frames to be delivered More... | |
| bool | isp0OutputRequested {false} |
true if the client wants frames to be delivered from the first ISP output More... | |
| bool | isp1OutputRequested {false} |
true if the client wants frames to be delivered from the second ISP output More... | |
| bool | isp2OutputRequested {false} |
true if the client wants frames to be delivered from the third ISP output More... | |
| NvSIPLDownscaleCropCfg | downscaleCropCfg {} |
| Holds a downscale and crop configuration. More... | |
| NvSIPLIspStatsOverrideSetting | statsOverrideSettings {} |
| Holds ISP statistics override parameters. More... | |
| NvSIPLImageGroupWriter * | imageGroupWriter {nullptr} |
| Holds a pointer to an NvSIPLImageGroupWriter. More... | |
| bool | disableSubframe {false} |
| Subframe pipeline feature processes frames of pixel data in a number of slices determined by sliceCount, allowing for latency savings through optimized scheduling. More... | |
| uint16_t | sliceCount {0} |
| Holds number of slices for ISP slicing configuration. More... | |
| NvSIPLPipelineBufferCfg | bufferCfg {} |
| Holds maximum buffer pool size for each output channel configuration. More... | |
Field Documentation
◆ bufferCfg
| NvSIPLPipelineBufferCfg nvsipl::NvSIPLPipelineConfiguration::bufferCfg {} |
Holds maximum buffer pool size for each output channel configuration.
Definition at line 449 of file NvSIPLPipelineMgr.hpp.
◆ captureOutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::captureOutputRequested {false} |
true if the client wants capture output frames to be delivered
Definition at line 403 of file NvSIPLPipelineMgr.hpp.
◆ disableSubframe
| bool nvsipl::NvSIPLPipelineConfiguration::disableSubframe {false} |
Subframe pipeline feature processes frames of pixel data in a number of slices determined by sliceCount, allowing for latency savings through optimized scheduling.
true if the client wants to disable the subframe feature Note: This feature is disabled by default when using YUV cameras or TPG configurations.
Definition at line 437 of file NvSIPLPipelineMgr.hpp.
◆ downscaleCropCfg
| NvSIPLDownscaleCropCfg nvsipl::NvSIPLPipelineConfiguration::downscaleCropCfg {} |
Holds a downscale and crop configuration.
Definition at line 415 of file NvSIPLPipelineMgr.hpp.
◆ imageGroupWriter
| NvSIPLImageGroupWriter* nvsipl::NvSIPLPipelineConfiguration::imageGroupWriter {nullptr} |
Holds a pointer to an NvSIPLImageGroupWriter.
Definition at line 426 of file NvSIPLPipelineMgr.hpp.
◆ isp0OutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::isp0OutputRequested {false} |
true if the client wants frames to be delivered from the first ISP output
Definition at line 406 of file NvSIPLPipelineMgr.hpp.
◆ isp1OutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::isp1OutputRequested {false} |
true if the client wants frames to be delivered from the second ISP output
Definition at line 409 of file NvSIPLPipelineMgr.hpp.
◆ isp2OutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::isp2OutputRequested {false} |
true if the client wants frames to be delivered from the third ISP output
Definition at line 412 of file NvSIPLPipelineMgr.hpp.
◆ sliceCount
| uint16_t nvsipl::NvSIPLPipelineConfiguration::sliceCount {0} |
Holds number of slices for ISP slicing configuration.
Valid range: [0, 16] Note: If sliceCount is 0, Default ISP slicing configuration will be used.
Definition at line 444 of file NvSIPLPipelineMgr.hpp.
◆ statsOverrideSettings
| NvSIPLIspStatsOverrideSetting nvsipl::NvSIPLPipelineConfiguration::statsOverrideSettings {} |
Holds ISP statistics override parameters.
ISP statistcis settings enabled in NvSIPLIspStatsOverrideSetting will override the statistics settings provided in NITO
Definition at line 422 of file NvSIPLPipelineMgr.hpp.
The documentation for this struct was generated from the following file:
