Detailed Description
Holds IOFA Process Frame API parameters.
Definition at line 548 of file nvmedia_iofa.h.
Data Fields | |
| bool | rightDispMap |
| Enable right view disparity map. More... | |
| uint8_t | currentPydLevel |
| Current level to process in Pyd SGM LEVEL Mode. More... | |
| bool | noopMode |
| noop flag true Avoid ofa processing and signal frame done false Normal ofa processing (default) More... | |
| NvMediaIofaPydHintParams | pydHintParams |
| Pyramid hints parameters. More... | |
| NvMediaIofaConstHintParams | pydConstHintParams |
| Pyramid Const Hints Parameters. More... | |
| NvMediaIofaExtHintParams | pydExtHintParams |
| Pyramid External Hints Parameters. More... | |
Field Documentation
◆ currentPydLevel
| uint8_t NvMediaIofaProcessParams::currentPydLevel |
Current level to process in Pyd SGM LEVEL Mode.
Applicable only for Orin OFA.
valid range of values is between 0 to ofaPydLevel-1.
Definition at line 559 of file nvmedia_iofa.h.
◆ noopMode
| bool NvMediaIofaProcessParams::noopMode |
noop flag
true Avoid ofa processing and signal frame done
false Normal ofa processing (default)
Definition at line 564 of file nvmedia_iofa.h.
◆ pydConstHintParams
| NvMediaIofaConstHintParams NvMediaIofaProcessParams::pydConstHintParams |
Pyramid Const Hints Parameters.
Definition at line 568 of file nvmedia_iofa.h.
◆ pydExtHintParams
| NvMediaIofaExtHintParams NvMediaIofaProcessParams::pydExtHintParams |
Pyramid External Hints Parameters.
Definition at line 570 of file nvmedia_iofa.h.
◆ pydHintParams
| NvMediaIofaPydHintParams NvMediaIofaProcessParams::pydHintParams |
Pyramid hints parameters.
Definition at line 566 of file nvmedia_iofa.h.
◆ rightDispMap
| bool NvMediaIofaProcessParams::rightDispMap |
Enable right view disparity map.
Applicable only for Stereo mode
false to disable right view disparity generation
true to enable right view disparity generation
If enabled, stereo disparity is estimated for right view w.r.t. left view
Definition at line 555 of file nvmedia_iofa.h.
The documentation for this struct was generated from the following file:
