Detailed Description
Holds the sensor attributes.
Definition at line 116 of file NvSIPLCDICommon.h.
Data Fields | |
| char | sensorName [DEVBLK_CDI_MAX_SENSOR_NAME_LENGTH] |
| Holds the name as a string. More... | |
| uint32_t | sensorCFA |
| Holds the CFA attribute. More... | |
| uint8_t | sensorFuseId [DEVBLK_CDI_MAX_FUSE_ID_LENGTH] |
| Holds the fuse ID attribute. More... | |
| uint8_t | numActiveExposures |
| Holds the number of active exposures attribute. More... | |
| DevBlkCDIAttrRange | sensorExpRange [DEVBLK_CDI_MAX_EXPOSURES] |
| Holds the sensor exposure ranges (in seconds) for active exposures. More... | |
| DevBlkCDIAttrRange | sensorGainRange [DEVBLK_CDI_MAX_EXPOSURES] |
| Holds the sensor gain ranges for active exposures. More... | |
| DevBlkCDIAttrRange | sensorWhiteBalanceRange [DEVBLK_CDI_MAX_EXPOSURES] |
| Holds the sensor white balance ranges for active exposures. More... | |
| float_t | sensorGainFactor [DEVBLK_CDI_MAX_EXPOSURES] |
| Holds the additional sensor gain factor between active exposures. More... | |
| uint32_t | numFrameReportBytes |
| Holds the number of frame report bytes supported by the sensor. More... | |
| DevBlkCDIAttrQuantizationStepSize | sensorQuantizationStepSize |
| Holds the quantization step size parameters for non-HDR sensors. More... | |
Field Documentation
◆ numActiveExposures
| uint8_t DevBlkCDISensorAttributes::numActiveExposures |
Holds the number of active exposures attribute.
Valid Range: [1, DEVBLK_CDI_MAX_EXPOSURES]
Definition at line 139 of file NvSIPLCDICommon.h.
◆ numFrameReportBytes
| uint32_t DevBlkCDISensorAttributes::numFrameReportBytes |
Holds the number of frame report bytes supported by the sensor.
If not supported, set to zero. Valid Range: [1 , DEVBLK_CDI_MAX_FRAME_REPORT_BYTES]
Definition at line 205 of file NvSIPLCDICommon.h.
◆ sensorCFA
| uint32_t DevBlkCDISensorAttributes::sensorCFA |
Holds the CFA attribute.
If not supported, set to zero. Valid Range:
- Should be a valid NVSIPL_PIXEL_ORDER
- Refer to INvSIPLCamera::RegisterImages documentation for supported component orders
Definition at line 128 of file NvSIPLCDICommon.h.
◆ sensorExpRange
| DevBlkCDIAttrRange DevBlkCDISensorAttributes::sensorExpRange[DEVBLK_CDI_MAX_EXPOSURES] |
Holds the sensor exposure ranges (in seconds) for active exposures.
Only the first numActiveExposures elements are valid.
Valid Ranges:
- min [0.0, 100.0]
- max [min, 100.0]
Definition at line 150 of file NvSIPLCDICommon.h.
◆ sensorFuseId
| uint8_t DevBlkCDISensorAttributes::sensorFuseId[DEVBLK_CDI_MAX_FUSE_ID_LENGTH] |
Holds the fuse ID attribute.
If not supported, set to NULL.
Definition at line 133 of file NvSIPLCDICommon.h.
◆ sensorGainFactor
| float_t DevBlkCDISensorAttributes::sensorGainFactor[DEVBLK_CDI_MAX_EXPOSURES] |
Holds the additional sensor gain factor between active exposures.
Only the first numActiveExposures elements are valid.
Valid Range: [0.0, 1000.0]
Element holds the sensitivity ratio between capture 0 and capture a. It is usually set to 1.
The HDR ratio between exposure a and exposure b can be computed as:
\( hdrRatio_{ab} = ( Et[a] * Gain[a] * sensorGainFactor[a] ) / (Et[b] * Gain[b] * sensorGainFactor[b]) \)
Where:
- Et[a] = exposure time value for HDR exposure a.
- Gain[a] = sensor gain value for HDR exposure a.
- sensorGainFactor[a] = sensor gain factor for HDR exposure a.
- Et[b] = exposure time value for HDR exposure b.
- Gain[b] = sensor gain value for HDR exposure b.
- sensorGainFactor[b] = sensor gain factor for HDR exposure b.
Definition at line 198 of file NvSIPLCDICommon.h.
◆ sensorGainRange
| DevBlkCDIAttrRange DevBlkCDISensorAttributes::sensorGainRange[DEVBLK_CDI_MAX_EXPOSURES] |
Holds the sensor gain ranges for active exposures.
Only the first numActiveExposures elements are valid.
Valid Ranges:
- min [0.0, 1000.0]
- max [min, 1000.0]
Definition at line 161 of file NvSIPLCDICommon.h.
◆ sensorName
| char DevBlkCDISensorAttributes::sensorName[DEVBLK_CDI_MAX_SENSOR_NAME_LENGTH] |
Holds the name as a string.
If not supported, set to NULL.
Definition at line 120 of file NvSIPLCDICommon.h.
◆ sensorQuantizationStepSize
| DevBlkCDIAttrQuantizationStepSize DevBlkCDISensorAttributes::sensorQuantizationStepSize |
Holds the quantization step size parameters for non-HDR sensors.
Definition at line 210 of file NvSIPLCDICommon.h.
◆ sensorWhiteBalanceRange
| DevBlkCDIAttrRange DevBlkCDISensorAttributes::sensorWhiteBalanceRange[DEVBLK_CDI_MAX_EXPOSURES] |
Holds the sensor white balance ranges for active exposures.
Only the first numActiveExposures elements are valid.
Valid Ranges:
- min [0.0, 1000.0]
- max [min, 1000.0]
Definition at line 172 of file NvSIPLCDICommon.h.
The documentation for this struct was generated from the following file:
