Detailed Description
Structure containing ISP Stats information.
Definition at line 182 of file NvSIPLControlAutoDef.hpp.
Data Fields | |
| const NvSiplISPLocalAvgClipStatsData * | lacData [2] |
| Holds pointers to 2 LAC stats data, defined in NvSIPLISPStat.hpp. More... | |
| const NvSiplISPLocalAvgClipStats * | lacSettings [2] |
| Holds pointers to 2 LAC stats settings, defined in NvSIPLISPStat.hpp. More... | |
| const NvSiplISPHistogramStatsData * | histData [2] |
| Holds pointers to 2 Histogram stats data, defined in NvSIPLISPStat.hpp. More... | |
| const NvSiplISPHistogramStats * | histSettings [2] |
| Holds pointers to 2 Histogram stats settings, defined in NvSIPLISPStat.hpp. More... | |
| const NvSiplISPFlickerBandStatsData * | fbStatsData |
| Holds pointer to Flicker Band stats data, defined in NvSIPLISPStat.hpp. More... | |
| const NvSiplISPFlickerBandStats * | fbStatsSettings |
| Holds pointer to Flicker Band stats settings, defined in NvSIPLISPStat.hpp. More... | |
Field Documentation
◆ fbStatsData
| const NvSiplISPFlickerBandStatsData* nvsipl::SiplControlIspStatsInfo::fbStatsData |
Holds pointer to Flicker Band stats data, defined in NvSIPLISPStat.hpp.
This variable is not supported in SIPL Control Auto.
- Supported values for bandCount: [1, 256]
- Supported values for luminance: [0.0, 1.0]
Definition at line 215 of file NvSIPLControlAutoDef.hpp.
◆ fbStatsSettings
| const NvSiplISPFlickerBandStats* nvsipl::SiplControlIspStatsInfo::fbStatsSettings |
Holds pointer to Flicker Band stats settings, defined in NvSIPLISPStat.hpp.
This variable is not supported in SIPL Control Auto.
Definition at line 220 of file NvSIPLControlAutoDef.hpp.
◆ histData
| const NvSiplISPHistogramStatsData* nvsipl::SiplControlIspStatsInfo::histData[2] |
Holds pointers to 2 Histogram stats data, defined in NvSIPLISPStat.hpp.
- Supported values for data: [0, number of pixels per color component in the ROI defined in histSettings variable].
- Supported values for excludedCount: [0, number of pixels per color component in the ROI defined in histSettings variable].
Definition at line 204 of file NvSIPLControlAutoDef.hpp.
◆ histSettings
| const NvSiplISPHistogramStats* nvsipl::SiplControlIspStatsInfo::histSettings[2] |
Holds pointers to 2 Histogram stats settings, defined in NvSIPLISPStat.hpp.
Definition at line 208 of file NvSIPLControlAutoDef.hpp.
◆ lacData
| const NvSiplISPLocalAvgClipStatsData* nvsipl::SiplControlIspStatsInfo::lacData[2] |
Holds pointers to 2 LAC stats data, defined in NvSIPLISPStat.hpp.
- Supported values for numWindowsH: [1, 32]
- Supported values for numWindowsV: [1, 32]
- Supported values for average: [0.0, 1.0]
- Supported values for maskedOffCount: [0, M]
- Supported values for clippedCount: [0, M] M is the number of pixels per color component in the window.
Definition at line 192 of file NvSIPLControlAutoDef.hpp.
◆ lacSettings
| const NvSiplISPLocalAvgClipStats* nvsipl::SiplControlIspStatsInfo::lacSettings[2] |
Holds pointers to 2 LAC stats settings, defined in NvSIPLISPStat.hpp.
Definition at line 197 of file NvSIPLControlAutoDef.hpp.
The documentation for this struct was generated from the following file:
