Detailed Description
Defines the camera pipeline configuration.
Definition at line 302 of file NvSIPLPipelineMgr.hpp.
Data Fields | |
| bool | captureOutputRequested {false} |
true if the client wants capture output frames to be delivered More... | |
| bool | isp0OutputRequested {false} |
true if the client wants frames to be delivered from the first ISP output More... | |
| bool | isp1OutputRequested {false} |
true if the client wants frames to be delivered from the second ISP output More... | |
| bool | isp2OutputRequested {false} |
true if the client wants frames to be delivered from the third ISP output More... | |
| NvSIPLDownscaleCropCfg | downscaleCropCfg {} |
| Holds a downscale and crop configuration. More... | |
| NvSIPLIspStatsOverrideSetting | statsOverrideSettings {} |
| Holds ISP statistics override parameters. More... | |
| NvSIPLImageGroupWriter * | imageGroupWriter {nullptr} |
| Holds a pointer to an NvSIPLImageGroupWriter. More... | |
| bool | disableSubframe {false} |
true if the client wants to disable the subframe feature More... | |
Field Documentation
◆ captureOutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::captureOutputRequested {false} |
true if the client wants capture output frames to be delivered
Definition at line 305 of file NvSIPLPipelineMgr.hpp.
◆ disableSubframe
| bool nvsipl::NvSIPLPipelineConfiguration::disableSubframe {false} |
true if the client wants to disable the subframe feature
Definition at line 330 of file NvSIPLPipelineMgr.hpp.
◆ downscaleCropCfg
| NvSIPLDownscaleCropCfg nvsipl::NvSIPLPipelineConfiguration::downscaleCropCfg {} |
Holds a downscale and crop configuration.
Definition at line 317 of file NvSIPLPipelineMgr.hpp.
◆ imageGroupWriter
| NvSIPLImageGroupWriter* nvsipl::NvSIPLPipelineConfiguration::imageGroupWriter {nullptr} |
Holds a pointer to an NvSIPLImageGroupWriter.
Definition at line 327 of file NvSIPLPipelineMgr.hpp.
◆ isp0OutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::isp0OutputRequested {false} |
true if the client wants frames to be delivered from the first ISP output
Definition at line 308 of file NvSIPLPipelineMgr.hpp.
◆ isp1OutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::isp1OutputRequested {false} |
true if the client wants frames to be delivered from the second ISP output
Definition at line 311 of file NvSIPLPipelineMgr.hpp.
◆ isp2OutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::isp2OutputRequested {false} |
true if the client wants frames to be delivered from the third ISP output
Definition at line 314 of file NvSIPLPipelineMgr.hpp.
◆ statsOverrideSettings
| NvSIPLIspStatsOverrideSetting nvsipl::NvSIPLPipelineConfiguration::statsOverrideSettings {} |
Holds ISP statistics override parameters.
ISP statistcis settings enabled in @NvSIPLIspStatsOverrideSetting will override the statistics settings provided in NITO
Definition at line 324 of file NvSIPLPipelineMgr.hpp.
The documentation for this struct was generated from the following file:
