Detailed Description
Holds the encoder output extradata configuration.
Definition at line 203 of file nvmedia_iep_output_extradata.h.
Data Fields | |
| uint32_t | ulExtraDataSize |
| Size of this extradata structure. More... | |
| bool | bkeyFrame |
| Format of input H264 data. More... | |
| bool | bEndOfFrame |
| Slice end or frame end in the packet for application to handle packets When slice encode is completed but not complete frame then it will set bEndOfFrame to false. More... | |
| uint32_t | ulHdrSize |
| Size of SPS/PPS header if it passed with output buffer. More... | |
| int16_t | AvgQP |
| Average QP index of the encoded frame. More... | |
| bool | bIsGoldenOrAlternateFrame |
| Flag for vp8 reference frame information. More... | |
| bool | bValidReconCRC |
| Whether Recon CRC for Recon frame is present. More... | |
| uint32_t | ulReconCRC_Y |
| Recon CRC for Y component when ReconCRC generation is enabled. More... | |
| uint32_t | ulReconCRC_U |
| Recon CRC for U component when ReconCRC generation is enabled. More... | |
| uint32_t | ulReconCRC_V |
| Recon CRC for V component when ReconCRC generation is enabled. More... | |
| uint32_t | ulFrameMinQP |
| Rate Control Feedback. More... | |
| uint32_t | ulFrameMaxQP |
| Maximum QP used for this frame. More... | |
| bool | bRPSFeedback |
| RPS Feedback. More... | |
| uint32_t | ulCurrentRefFrameId |
| frame id of reference frame to be used for motion search, ignored for IDR. More... | |
| uint32_t | ulActiveRefFrames |
| Number of valid entries in RPS. More... | |
| NvMediaEncodeFrameFullProp | RPSList [NVMEDIA_ENCODE_MAX_RPS_SIZE] |
| RPS List including most recent frame if it is reference frame. More... | |
| bool | bMVbufferdump |
| Set if bitstream buffer contains MV Buffer dump. More... | |
| uint32_t | MVBufferDumpSize |
| Size of the MV buffer, including NvMediaEncodeMVBufferHeader and NvMediaEncodeMVData for each macroblock, as per the format defined in NvMediaEncodeMVBufferHeader. More... | |
| uint32_t | MVBufferDumpStartOffset |
| Encoded motion vector buffer dump start offset in the bitstream. More... | |
| NvMediaFrameStats | FrameStats |
| Encoder Profiling stats. More... | |
| uint32_t | ulHrdBitrate |
| hrdBitrate to be used to calculate RC stats. More... | |
| uint32_t | ulVbvBufSize |
| vbvBufSize to be used to compute RC stats. More... | |
| NvMediaVideoCodec | codec |
| Codec Type. More... | |
| NvMediaEncodeCodecExData | codecExData |
| Codec specific extradata. More... | |
Field Documentation
◆ AvgQP
| int16_t NvMediaEncodeOutputExtradata::AvgQP |
Average QP index of the encoded frame.
Definition at line 221 of file nvmedia_iep_output_extradata.h.
◆ bEndOfFrame
| bool NvMediaEncodeOutputExtradata::bEndOfFrame |
Slice end or frame end in the packet for application to handle packets When slice encode is completed but not complete frame then it will set bEndOfFrame to false.
After frame encode is complete, it will set bEndOfFrame to true.
- Note
- This feature is not supported.
Definition at line 217 of file nvmedia_iep_output_extradata.h.
◆ bIsGoldenOrAlternateFrame
| bool NvMediaEncodeOutputExtradata::bIsGoldenOrAlternateFrame |
Flag for vp8 reference frame information.
- Note
- This feature is not supported.
Definition at line 224 of file nvmedia_iep_output_extradata.h.
◆ bkeyFrame
| bool NvMediaEncodeOutputExtradata::bkeyFrame |
Format of input H264 data.
- Note
- This feature is not supported. Use NvMediaEncodeCodecExData::eFrameType instead.
Definition at line 211 of file nvmedia_iep_output_extradata.h.
◆ bMVbufferdump
| bool NvMediaEncodeOutputExtradata::bMVbufferdump |
Set if bitstream buffer contains MV Buffer dump.
To enable this feature, NVMEDIA_ENCODE_CONFIG_H264_ENABLE_MV_BUFFER_DUMP should be bit-ORd in NvMediaEncodeConfigH264::features
When this is set, NvMediaEncodeMVBufferHeader and array of NvMediaEncodeMVData (one for each macro block - contiguously in memory) will follow the encoded bitstream output at an offset defined in NvMediaEncodeOutputExtradata::MVBufferDumpStartOffset
Definition at line 265 of file nvmedia_iep_output_extradata.h.
◆ bRPSFeedback
| bool NvMediaEncodeOutputExtradata::bRPSFeedback |
RPS Feedback.
Reference Picture Set data output enabled.
- Note
- This feature is not supported.
Definition at line 245 of file nvmedia_iep_output_extradata.h.
◆ bValidReconCRC
| bool NvMediaEncodeOutputExtradata::bValidReconCRC |
Whether Recon CRC for Recon frame is present.
- Note
- This feature is not supported.
Definition at line 227 of file nvmedia_iep_output_extradata.h.
◆ codec
| NvMediaVideoCodec NvMediaEncodeOutputExtradata::codec |
Codec Type.
Definition at line 288 of file nvmedia_iep_output_extradata.h.
◆ codecExData
| NvMediaEncodeCodecExData NvMediaEncodeOutputExtradata::codecExData |
Codec specific extradata.
Definition at line 290 of file nvmedia_iep_output_extradata.h.
◆ FrameStats
| NvMediaFrameStats NvMediaEncodeOutputExtradata::FrameStats |
Encoder Profiling stats.
- Note
- This feature is not supported.
Definition at line 280 of file nvmedia_iep_output_extradata.h.
◆ MVBufferDumpSize
| uint32_t NvMediaEncodeOutputExtradata::MVBufferDumpSize |
Size of the MV buffer, including NvMediaEncodeMVBufferHeader and NvMediaEncodeMVData for each macroblock, as per the format defined in NvMediaEncodeMVBufferHeader.
This is set to a non-zero value only if there was sufficient space in bitstream buffer to store the MV Buffer data.
Definition at line 271 of file nvmedia_iep_output_extradata.h.
◆ MVBufferDumpStartOffset
| uint32_t NvMediaEncodeOutputExtradata::MVBufferDumpStartOffset |
Encoded motion vector buffer dump start offset in the bitstream.
This is the location in the bitstream where the NvMediaEncodeMVBufferHeader starts, followed by NvMediaEncodeMVData data. Motion vector dump is appended at the end of encoded bistream buffer with 8 byte aligned position.
Definition at line 277 of file nvmedia_iep_output_extradata.h.
◆ RPSList
| NvMediaEncodeFrameFullProp NvMediaEncodeOutputExtradata::RPSList[NVMEDIA_ENCODE_MAX_RPS_SIZE] |
RPS List including most recent frame if it is reference frame.
- Note
- This feature is not supported.
Definition at line 254 of file nvmedia_iep_output_extradata.h.
◆ ulActiveRefFrames
| uint32_t NvMediaEncodeOutputExtradata::ulActiveRefFrames |
Number of valid entries in RPS.
- Note
- This feature is not supported.
Definition at line 251 of file nvmedia_iep_output_extradata.h.
◆ ulCurrentRefFrameId
| uint32_t NvMediaEncodeOutputExtradata::ulCurrentRefFrameId |
frame id of reference frame to be used for motion search, ignored for IDR.
- Note
- This feature is not supported.
Definition at line 248 of file nvmedia_iep_output_extradata.h.
◆ ulExtraDataSize
| uint32_t NvMediaEncodeOutputExtradata::ulExtraDataSize |
Size of this extradata structure.
This needs to be filled correctly by the client to sizeof(NvMediaEncodeOutputExtradata). This size is used as sanity check before writing output extradata on this buffer.
Definition at line 207 of file nvmedia_iep_output_extradata.h.
◆ ulFrameMaxQP
| uint32_t NvMediaEncodeOutputExtradata::ulFrameMaxQP |
Maximum QP used for this frame.
Definition at line 241 of file nvmedia_iep_output_extradata.h.
◆ ulFrameMinQP
| uint32_t NvMediaEncodeOutputExtradata::ulFrameMinQP |
Rate Control Feedback.
Minimum QP used for this frame
Definition at line 239 of file nvmedia_iep_output_extradata.h.
◆ ulHdrSize
| uint32_t NvMediaEncodeOutputExtradata::ulHdrSize |
Size of SPS/PPS header if it passed with output buffer.
Definition at line 219 of file nvmedia_iep_output_extradata.h.
◆ ulHrdBitrate
| uint32_t NvMediaEncodeOutputExtradata::ulHrdBitrate |
hrdBitrate to be used to calculate RC stats.
- Note
- This feature is not supported.
Definition at line 283 of file nvmedia_iep_output_extradata.h.
◆ ulReconCRC_U
| uint32_t NvMediaEncodeOutputExtradata::ulReconCRC_U |
Recon CRC for U component when ReconCRC generation is enabled.
- Note
- This feature is not supported.
Definition at line 233 of file nvmedia_iep_output_extradata.h.
◆ ulReconCRC_V
| uint32_t NvMediaEncodeOutputExtradata::ulReconCRC_V |
Recon CRC for V component when ReconCRC generation is enabled.
- Note
- This feature is not supported.
Definition at line 236 of file nvmedia_iep_output_extradata.h.
◆ ulReconCRC_Y
| uint32_t NvMediaEncodeOutputExtradata::ulReconCRC_Y |
Recon CRC for Y component when ReconCRC generation is enabled.
- Note
- This feature is not supported.
Definition at line 230 of file nvmedia_iep_output_extradata.h.
◆ ulVbvBufSize
| uint32_t NvMediaEncodeOutputExtradata::ulVbvBufSize |
vbvBufSize to be used to compute RC stats.
- Note
- This feature is not supported.
Definition at line 286 of file nvmedia_iep_output_extradata.h.
The documentation for this struct was generated from the following file:
