Detailed Description
Defines the control info.
Definition at line 53 of file NvSIPLISPStructs.hpp.
Data Fields | |
| bool | valid |
| Holds a flag to determine whether or not the control info is valid. More... | |
| float_t | alpha |
| Holds power factor for isp statistics compression. More... | |
| bool | isLuminanceCalibrated |
| Holds a flag indicating if the sensor is luminance calibrated. More... | |
| double_t | luminanceCalibrationFactor |
| (note: parameter to be deprecated starting 6.0.7.0) Holds a luminance calibration factor ( K / f^2 ) for luminance calibrated sensors. More... | |
| float_t | luminanceCalibrationMatrix [NVSIPL_LUMINANCE_CALIB_MATRIX_SIZE][NVSIPL_LUMINANCE_CALIB_MATRIX_SIZE] |
| Holds the luminance calibration matrix for the sensor. More... | |
| SiplControlAutoAwbGain | wbGainTotal |
| Holds the total white balance gains, which includes both sensor channel and ISP gains. More... | |
| float_t | cct |
| Holds the correlated color temperature. More... | |
| float_t | brightnessKey |
| Holds the scene brightness key. More... | |
| float_t | sceneDynamicRange |
| Holds the scene dynamic range. More... | |
| float_t | sceneBrightness |
| Holds the scene brightness level. More... | |
| float_t | rawImageMidTone |
| Holds the midtone value of the raw image. More... | |
| NvSiplISPGlobalToneMapInfo | gtmSplineInfo |
| Holds the global tonemap block, containing a set of spline control points. More... | |
Field Documentation
◆ alpha
| float_t nvsipl::NvSiplControlInfo::alpha |
Holds power factor for isp statistics compression.
Definition at line 58 of file NvSIPLISPStructs.hpp.
◆ brightnessKey
| float_t nvsipl::NvSiplControlInfo::brightnessKey |
Holds the scene brightness key.
Definition at line 88 of file NvSIPLISPStructs.hpp.
◆ cct
| float_t nvsipl::NvSiplControlInfo::cct |
Holds the correlated color temperature.
Definition at line 86 of file NvSIPLISPStructs.hpp.
◆ gtmSplineInfo
| NvSiplISPGlobalToneMapInfo nvsipl::NvSiplControlInfo::gtmSplineInfo |
Holds the global tonemap block, containing a set of spline control points.
Definition at line 96 of file NvSIPLISPStructs.hpp.
◆ isLuminanceCalibrated
| bool nvsipl::NvSiplControlInfo::isLuminanceCalibrated |
Holds a flag indicating if the sensor is luminance calibrated.
Definition at line 60 of file NvSIPLISPStructs.hpp.
◆ luminanceCalibrationFactor
| double_t nvsipl::NvSiplControlInfo::luminanceCalibrationFactor |
(note: parameter to be deprecated starting 6.0.7.0) Holds a luminance calibration factor ( K / f^2 ) for luminance calibrated sensors.
Definition:
N = K * (t*S / (f^2)) * L N: pixel value (e.g. RGGB channel average value) K: calibration constant t: sensor exposure time in seconds (if number of exposures > 1, use long exposure time value) S: sensor gain (if number of exposures > 1, use long exposure gain value) f: aperture number (f-stop) L: Luminance
Let luminanceCalibrationFactor = K / (f^2) = N / (t*S*L)
Definition at line 77 of file NvSIPLISPStructs.hpp.
◆ luminanceCalibrationMatrix
| float_t nvsipl::NvSiplControlInfo::luminanceCalibrationMatrix[NVSIPL_LUMINANCE_CALIB_MATRIX_SIZE][NVSIPL_LUMINANCE_CALIB_MATRIX_SIZE] |
Holds the luminance calibration matrix for the sensor.
- Supported values [1E-12, 1E12]
Definition at line 82 of file NvSIPLISPStructs.hpp.
◆ rawImageMidTone
| float_t nvsipl::NvSiplControlInfo::rawImageMidTone |
Holds the midtone value of the raw image.
Definition at line 94 of file NvSIPLISPStructs.hpp.
◆ sceneBrightness
| float_t nvsipl::NvSiplControlInfo::sceneBrightness |
Holds the scene brightness level.
Definition at line 92 of file NvSIPLISPStructs.hpp.
◆ sceneDynamicRange
| float_t nvsipl::NvSiplControlInfo::sceneDynamicRange |
Holds the scene dynamic range.
Definition at line 90 of file NvSIPLISPStructs.hpp.
◆ valid
| bool nvsipl::NvSiplControlInfo::valid |
Holds a flag to determine whether or not the control info is valid.
If no ISP processing occurs this value is false.
Definition at line 56 of file NvSIPLISPStructs.hpp.
◆ wbGainTotal
| SiplControlAutoAwbGain nvsipl::NvSiplControlInfo::wbGainTotal |
Holds the total white balance gains, which includes both sensor channel and ISP gains.
Definition at line 84 of file NvSIPLISPStructs.hpp.
The documentation for this struct was generated from the following file:
