Detailed Description
SIPL ISP Statistics Override Parameters.
ISP Statistics settings enabled in @NvSIPLIspStatsOverrideSetting will override the corresponding statistics settings provided in NITO.
note: ISP histStats[0] and lacStats[0] statistics are consumed by internal algorithms to generate new sensor and ISP settings. Incorrect usage or disabling these statistics blocks would result in failure or image quality degradation. Please refer to the safety manual for guidance on overriding histStats[0] and lacStats[0] statistics settings.
Definition at line 616 of file NvSIPLISPStat.hpp.
Data Fields | |
| NvSiplBool | enableHistStatsOverride [2] |
| boolean flag to enable histogram statistics settings override More... | |
| NvSiplISPHistogramStatsOverride | histStats [2] |
| Structure containing override settings for histogram statistics block. More... | |
| NvSiplBool | enableLacStatsOverride [2] |
| boolean flag to enable local average clip statistics settings override More... | |
| NvSiplISPLocalAvgClipStats | lacStats [2] |
| Structure containing override settings for local average clip statistics block. More... | |
| NvSiplBool | enableBpStatsOverride [1] |
| boolean flag to enable bad pixel statistics settings override More... | |
| NvSiplISPBadPixelStats | bpStats [1] |
| Structure containing override settings for bad pixel statistics block. More... | |
Field Documentation
◆ bpStats
| NvSiplISPBadPixelStats nvsipl::NvSIPLIspStatsOverrideSetting::bpStats[1] |
Structure containing override settings for bad pixel statistics block.
Definition at line 641 of file NvSIPLISPStat.hpp.
◆ enableBpStatsOverride
| NvSiplBool nvsipl::NvSIPLIspStatsOverrideSetting::enableBpStatsOverride[1] |
boolean flag to enable bad pixel statistics settings override
Definition at line 637 of file NvSIPLISPStat.hpp.
◆ enableHistStatsOverride
| NvSiplBool nvsipl::NvSIPLIspStatsOverrideSetting::enableHistStatsOverride[2] |
boolean flag to enable histogram statistics settings override
Definition at line 621 of file NvSIPLISPStat.hpp.
◆ enableLacStatsOverride
| NvSiplBool nvsipl::NvSIPLIspStatsOverrideSetting::enableLacStatsOverride[2] |
boolean flag to enable local average clip statistics settings override
Definition at line 629 of file NvSIPLISPStat.hpp.
◆ histStats
| NvSiplISPHistogramStatsOverride nvsipl::NvSIPLIspStatsOverrideSetting::histStats[2] |
Structure containing override settings for histogram statistics block.
Definition at line 625 of file NvSIPLISPStat.hpp.
◆ lacStats
| NvSiplISPLocalAvgClipStats nvsipl::NvSIPLIspStatsOverrideSetting::lacStats[2] |
Structure containing override settings for local average clip statistics block.
Definition at line 633 of file NvSIPLISPStat.hpp.
The documentation for this struct was generated from the following file:
