Detailed Description
SIPL ISP Histogram Statistics Override Params.
Definition at line 543 of file NvSIPLISPStat.hpp.
Data Fields | |
| NvSiplBool | enable |
| Holds a Boolean to enable histogram statistics Control block. More... | |
| float_t | offset |
| Holds offset to be applied to input data prior to bin mapping. More... | |
| uint8_t | knees [NVSIPL_ISP_HIST_KNEE_POINTS] |
| Holds bin index specifying different zones in the histogram. More... | |
| uint8_t | ranges [NVSIPL_ISP_HIST_KNEE_POINTS] |
| Holds \(log_2\) range of the pixel values to be considered for each zone. More... | |
| NvSiplRect | rectangularMask |
| Holds a rectangular mask for excluding pixels outside a specified area. More... | |
| NvSiplBool | ellipticalMaskEnable |
| Holds a Boolean to enable an elliptical mask for excluding pixels outside a specified area. More... | |
| NvSiplISPEllipse | ellipticalMask |
| Holds an elliptical mask for excluding pixels outside a specified area. More... | |
| NvSiplBool | disableLensShadingCorrection |
| boolean flag to disable lens shading compensation for histogram statistics block More... | |
Field Documentation
◆ disableLensShadingCorrection
| NvSiplBool nvsipl::NvSiplISPHistogramStatsOverride::disableLensShadingCorrection |
boolean flag to disable lens shading compensation for histogram statistics block
Definition at line 602 of file NvSIPLISPStat.hpp.
◆ ellipticalMask
| NvSiplISPEllipse nvsipl::NvSiplISPHistogramStatsOverride::ellipticalMask |
Holds an elliptical mask for excluding pixels outside a specified area.
Coordinates of the image top left and bottom right points are (0, 0) and (width, height), respectively.
- Supported values for X coordinate of the center: [0, input width]
- Supported values for Y coordinate of the center: [0, input height]
- Supported values for horizontal axis: [16, 2 x input width]
- Supported values for vertical axis: [16, 2 x input height]
- Supported values for angle: [0.0, 360.0]
Definition at line 598 of file NvSIPLISPStat.hpp.
◆ ellipticalMaskEnable
| NvSiplBool nvsipl::NvSiplISPHistogramStatsOverride::ellipticalMaskEnable |
Holds a Boolean to enable an elliptical mask for excluding pixels outside a specified area.
Definition at line 585 of file NvSIPLISPStat.hpp.
◆ enable
| NvSiplBool nvsipl::NvSiplISPHistogramStatsOverride::enable |
Holds a Boolean to enable histogram statistics Control block.
Definition at line 547 of file NvSIPLISPStat.hpp.
◆ knees
| uint8_t nvsipl::NvSiplISPHistogramStatsOverride::knees[NVSIPL_ISP_HIST_KNEE_POINTS] |
Holds bin index specifying different zones in the histogram.
Each zone can have a different number of bins.
- Supported values: [1, 255]
Definition at line 558 of file NvSIPLISPStat.hpp.
◆ offset
| float_t nvsipl::NvSiplISPHistogramStatsOverride::offset |
Holds offset to be applied to input data prior to bin mapping.
- Supported values: [-2.0, 2.0]
Definition at line 552 of file NvSIPLISPStat.hpp.
◆ ranges
| uint8_t nvsipl::NvSiplISPHistogramStatsOverride::ranges[NVSIPL_ISP_HIST_KNEE_POINTS] |
Holds \(log_2\) range of the pixel values to be considered for each zone.
The whole pixel range is divided into NVSIPL_ISP_HIST_KNEE_POINTS zones.
- Supported values: [0, 21]
Definition at line 565 of file NvSIPLISPStat.hpp.
◆ rectangularMask
| NvSiplRect nvsipl::NvSiplISPHistogramStatsOverride::rectangularMask |
Holds a rectangular mask for excluding pixels outside a specified area.
The coordinates of image top left and bottom right points are (0, 0) and (width, height), respectively. A rectangle ((right > left) && (bottom > top)), or must be ((0,0), (0,0)) to disable the rectangular mask.
The rectangle settings(x0, y0, x1, y1) must follow the constraints listed below:
- (x0 >= 0) and (y0 >= 0)
- x0 and x1 should be even
- (x1 <= image width) and (y1 <= image height)
- rectangle width(x1 - x0) >= 2 and height(y1 - y0) >= 2
Definition at line 580 of file NvSIPLISPStat.hpp.
The documentation for this struct was generated from the following file:
