Detailed Description
Defines the control info.
Definition at line 50 of file NvSIPLISPStructs.hpp.
Data Fields | |
| bool | valid |
| Holds a flag to determine whether or not the control info is valid. More... | |
| float_t | alpha |
| Holds power factor for isp statistics compression. More... | |
| bool | isLuminanceCalibrated |
| Holds a flag indicating if the sensor is luminance calibrated. More... | |
| double_t | luminanceCalibrationFactor |
| Holds a luminance calibration factor ( K / f^2 ) for luminance calibrated sensors. More... | |
| SiplControlAutoAwbGain | wbGainTotal |
| Holds the total white balance gains, which includes both sensor channel and ISP gains. More... | |
| float_t | cct |
| Holds the correlated color temperature. More... | |
| float_t | brightnessKey |
| Holds the scene brightness key. More... | |
| float_t | rawImageMidTone |
| Holds the midtone value of the raw image. More... | |
| NvSiplISPGlobalToneMapInfo | gtmSplineInfo |
| Holds the global tonemap block, containing a set of spline control points. More... | |
Field Documentation
◆ alpha
| float_t nvsipl::NvSiplControlInfo::alpha |
Holds power factor for isp statistics compression.
Definition at line 55 of file NvSIPLISPStructs.hpp.
◆ brightnessKey
| float_t nvsipl::NvSiplControlInfo::brightnessKey |
Holds the scene brightness key.
Definition at line 79 of file NvSIPLISPStructs.hpp.
◆ cct
| float_t nvsipl::NvSiplControlInfo::cct |
Holds the correlated color temperature.
Definition at line 77 of file NvSIPLISPStructs.hpp.
◆ gtmSplineInfo
| NvSiplISPGlobalToneMapInfo nvsipl::NvSiplControlInfo::gtmSplineInfo |
Holds the global tonemap block, containing a set of spline control points.
Definition at line 83 of file NvSIPLISPStructs.hpp.
◆ isLuminanceCalibrated
| bool nvsipl::NvSiplControlInfo::isLuminanceCalibrated |
Holds a flag indicating if the sensor is luminance calibrated.
Definition at line 57 of file NvSIPLISPStructs.hpp.
◆ luminanceCalibrationFactor
| double_t nvsipl::NvSiplControlInfo::luminanceCalibrationFactor |
Holds a luminance calibration factor ( K / f^2 ) for luminance calibrated sensors.
Definition:
N = K * (t*S / (f^2)) * L N: pixel value (e.g. RGGB channel average value) K: calibration constant t: sensor exposure time in seconds (if number of exposures > 1, use long exposure time value) S: sensor gain (if number of exposures > 1, use long exposure gain value) f: aperture number (f-stop) L: Luminance
Let luminanceCalibrationFactor = K / (f^2) = N / (t*S*L)
Definition at line 73 of file NvSIPLISPStructs.hpp.
◆ rawImageMidTone
| float_t nvsipl::NvSiplControlInfo::rawImageMidTone |
Holds the midtone value of the raw image.
Definition at line 81 of file NvSIPLISPStructs.hpp.
◆ valid
| bool nvsipl::NvSiplControlInfo::valid |
Holds a flag to determine whether or not the control info is valid.
If no ISP processing occurs this value is false.
Definition at line 53 of file NvSIPLISPStructs.hpp.
◆ wbGainTotal
| SiplControlAutoAwbGain nvsipl::NvSiplControlInfo::wbGainTotal |
Holds the total white balance gains, which includes both sensor channel and ISP gains.
Definition at line 75 of file NvSIPLISPStructs.hpp.
The documentation for this struct was generated from the following file:
