Detailed Description
Defines the camera pipeline configuration.
Definition at line 335 of file NvSIPLPipelineMgr.hpp.
Data Fields | |
| bool | captureOutputRequested {false} |
true if the client wants capture output frames to be delivered More... | |
| bool | isp0OutputRequested {false} |
true if the client wants frames to be delivered from the first ISP output More... | |
| bool | isp1OutputRequested {false} |
true if the client wants frames to be delivered from the second ISP output More... | |
| bool | isp2OutputRequested {false} |
true if the client wants frames to be delivered from the third ISP output More... | |
| NvSIPLDownscaleCropCfg | downscaleCropCfg {} |
| Holds a downscale and crop configuration. More... | |
| NvSIPLIspStatsOverrideSetting | statsOverrideSettings {} |
| Holds ISP statistics override parameters. More... | |
| NvSIPLImageGroupWriter * | imageGroupWriter {nullptr} |
| Holds a pointer to an NvSIPLImageGroupWriter. More... | |
| bool | disableSubframe {false} |
true if the client wants to disable the subframe feature More... | |
Field Documentation
◆ captureOutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::captureOutputRequested {false} |
true if the client wants capture output frames to be delivered
Definition at line 338 of file NvSIPLPipelineMgr.hpp.
◆ disableSubframe
| bool nvsipl::NvSIPLPipelineConfiguration::disableSubframe {false} |
true if the client wants to disable the subframe feature
Definition at line 365 of file NvSIPLPipelineMgr.hpp.
◆ downscaleCropCfg
| NvSIPLDownscaleCropCfg nvsipl::NvSIPLPipelineConfiguration::downscaleCropCfg {} |
Holds a downscale and crop configuration.
Definition at line 350 of file NvSIPLPipelineMgr.hpp.
◆ imageGroupWriter
| NvSIPLImageGroupWriter* nvsipl::NvSIPLPipelineConfiguration::imageGroupWriter {nullptr} |
Holds a pointer to an NvSIPLImageGroupWriter.
Definition at line 361 of file NvSIPLPipelineMgr.hpp.
◆ isp0OutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::isp0OutputRequested {false} |
true if the client wants frames to be delivered from the first ISP output
Definition at line 341 of file NvSIPLPipelineMgr.hpp.
◆ isp1OutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::isp1OutputRequested {false} |
true if the client wants frames to be delivered from the second ISP output
Definition at line 344 of file NvSIPLPipelineMgr.hpp.
◆ isp2OutputRequested
| bool nvsipl::NvSIPLPipelineConfiguration::isp2OutputRequested {false} |
true if the client wants frames to be delivered from the third ISP output
Definition at line 347 of file NvSIPLPipelineMgr.hpp.
◆ statsOverrideSettings
| NvSIPLIspStatsOverrideSetting nvsipl::NvSIPLPipelineConfiguration::statsOverrideSettings {} |
Holds ISP statistics override parameters.
ISP statistcis settings enabled in NvSIPLIspStatsOverrideSetting will override the statistics settings provided in NITO
Definition at line 357 of file NvSIPLPipelineMgr.hpp.
The documentation for this struct was generated from the following file:
