NVIDIA Clara AGX
NVIDIA Clara AGX Development Kit
The NVIDIA Clara AGX Development Kit delivers real-time AI and imaging for medical devices. By combining low-powered, NVIDIA Jetson AGX Xavier and RTX GPU with the NVIDIA Clara AGX SDK and the NVIDIA EGX stack, it’s easy to securely provision and remotely manage fleets of distributed medical instruments.
NVIDIA Clara AGX Software
NVIDIA Clara AGX SDK runs on the NVIDIA Clara AGX and Jetson platform and provides developers with capabilities to build end-to-end streaming workflows for medical imaging. It includes advanced samples for ultrasound video and endoscopy. Access to the NVIDIA Clara AGX SDK requires an NVIDIA Developer Account.
Details
Clara AGX Hardware
- Clara AGX Xavier Developer Kit (SKU #): Includes an NVIDIA RTX GPU and NVIDIA ConnectX-6 network interface card
Key Components
| Component | Function |
|---|---|
| NVIDIA RTX 6000 | Discrete GPU |
| Xavier AGX 32 GB DRAM Module | CPU, GPU and I/O Processing |
| Mellanox ConnectX-6 Smart Interconnect | Xavier AGX 32 GB DRAM Module |
| 250GB SSD | Removable Storage |
Specs
| CPU | 8-core Carmel ARM v8.2 64-bit CPU, 8MB L2 + 4MB L3 | |
| DRAM | 32GB 256-Bit LPDDR4x | 136.5GB/s | |
| GPU | (RTX 6000) | 4608-core Volta GPU with 576 Tensor Cores |
| (AGX Xavier) | 512-core Volta GPU with 64 Tensor Cores | |
| GPU Memory | (RTX 6000) | 24 GB GDDR6 |
| GPU FP32 Performance | (RTX 6000) | 16.3 TFLOPS |
| Storage | (AGX Xavier) | 32GB eMMC 5.1 |
| (Removable SSD) | 250 GB | |
| Power | 350 W | |
| Encode | (AGX Xavier) | Up to 2x 1000MP/sec |
| (RTX 6000) | Up to 1000MP/sec | |
| Decode | (AGX Xavier) | Up to 2x 1500MP/sec |
| (RTX 6000) | Up to 1500MP/sec |
I/O
| Input / Output | ||
|---|---|---|
| 1 x PCIe Gen4 x8 128 Gbps | (RDMA to GPU) | |
| 1 x PCIe Gen4 x8 128 Gbps | (to AGX Xavier) | |
| 2 x USB 3.1 Gen 2 | ||
| 1 x USB 2.0 | ||
| 1 x 100 Gbps Ethernet QSFP | (To Mellanox) | |
| 1 x 10 Gbps Ethernet RJ45 | (To Mellanox) | |
| 1 x 1 Gbps Ethernet RJ45 | (to AGX Xavier) | |
| 1 x SD Card | ||
| 1 x USB-C | Debug Interface | |
| Video Input | HDMI In | CSI In |
| Video Output | HDMI Out (from AGX Xavier) | DP Out (from RTX 6000) |
How to get it
The Clara AGX Developer Kit is available exclusively for members of the NVIDIA Clara Developer Partner Program. Register through our Developer Partner Program application and one of our NVIDIA Sales Representatives will contact you to determine next steps. Users may only join with a corporate or university email address.
How to set up
You will need:
- A host development PC
- Clara AGX Development Kit
- Clara AGX SDK available through our NVIDIA Developer Program
- Clara Guardian available through their Early Access Program
- NVIDIA Rivermax SDK available through their Early Access Program
The development environment for Clara AGX requires a host development PC (not included with the Clara AGX Developer Kit).
How to develop
Clara AGX SDK
Clara AGX SDK runs on the Jetson platform and provides developers with capabilities to build end-to-end streaming workflows for medical imaging. It includes advanced samples for ultrasound video and endoscopy. Access to the NVIDIA Clara AGX SDK requires an NVIDIA Developer Account.
SDK Features
- NVIDIA RTX support - Docker and CUDA, TensorRT, dGPU enablement
- NVIDIA Rivermax 100GbE streaming -Rivermax transport protocol streams data over ethernet directly into GPU GDDR DRAM using GPU Direct Technology
- NVIDIA Clara Guardian support - Build edge AI applications to improve patient care and operational efficiency using everyday sensors like cameras & microphones
- Windows Device mode support - I/O Driver provides Jetson AGX work in device mode on Windows 10 machine
- Endoscopy using NVIDIA DeepStream - Video-in and inference for endoscopy and other video-based modalities
- Sensor Processing - Support for camera serial interface
- AI endoscopy and ultrasound reference application
Additional Development Resources:
Documentation (PDF)
- Getting Started Guide: Clara AGX Getting Started Guide (PDF)
- SDK Documentation: Clara AGX SDK Documentation (PDF)
Blogs
Clara AGX Ecosystem Partners
Disclaimer: Clara SDKs and samples are for developmental purposes only and cannot be used directly for clinical procedures.
