Real-Time Rendering Effects and Techniques
Advanced Realtime Rendering Effects and Techniques. This collection of documents
cover some of NVIDIA's innovative research into the limits of present-day graphics
API's - and beyond.
To the Edge of the API |
And Beyond
- Samples from NVIDIA Graphics SDK 10.5:
- Clipmaps (Whitepaper)
- Clipmaps are a feature (first implemented on SGI workstations)
that allow mapping extremely high resolution textures to
terrains. The original SGI implementation required highly
specialized, custom hardware. The advanced features of the
NVIDIA® GeForce® 8800 now permit the same algorithm using
consumer hardware.
- HDR Rendering (Video)
- Demonstrates HDR rendering on the GeForce 8800 and DirectX10.
The GeForce 8800 supports new features to facilitate next-gen
HDR. There are new texture and render target formats, such as
R11G11B10F, which has the same memory requirements as standard
32-bit RGBA. The sample also demonstrates anti-aliasing
combined with HDR, including high-quality 16x Coverage Sample
Anti-Aliasing.
- Soft Particles (Whitepaper)
- Particle sprites in games commonly produce artifacts –
unnaturally sharp edges – where they intersect the rest of the
scene. This sample shows two ways to fade out flat sprites
against a 3D scene, softening the artificial edges. Two
solutions are implemented: one uses the ability of DirectX10 to
read the depth buffer as a texture; the other uses a more
conventional second render target to store depth values. - one
other rendering Z in a 2nd render target.
- GPU Blend Shapes (Whitepaper)
- This paper presents two methods for computing Blend Shapes on
the GPU. The technique produces hybrid, blended meshes by
combining a large number of input meshes. GPU generations prior
to GeForce 8800 had to use the vertex attributes to send
additional data for blend shapes. Because of the limited amount
of available attributes, few simultaneous blend shapes meshes
were possible. The GeForce 8800 permits a large number of input
meshes, with no fixed limit.
- Metaballs (Video)
- This sample demonstrates efficient use of DX10 geometry shader
to perform isosurface tessellation
- Instanced Tesselation (Whitepaper)
- This OpenGL example shows how to use bindable uniform buffers
and draw instanced in order to render tessellated curved
surfaces. The vertices and the indices are stored in buffer
objects and bound to the shader. Patches are drawn by rendering
a single tessellated quad multiple times, using instancing to
do this in a single call and the instance id to index the index
buffer. Indices are stored as integers using the integer
support in gpu shader4. This is idea is based on the Generic
Mesh Refinement On GPU paper.
- Simple Depth Float (Whitepaper)
- Simple Depth Float demonstrates the use of a floating point
depth buffer. The sample demonstrates the differences in depth
fighting between different depth buffer precisions, and it
demonstrates inverting the depth values to enhance precision
further when using a floating point depth buffer.
- Dual Depth Peeling (Whitepaper)
- This sample demonstrates how to implement depth peeling on
GeForce 8 using the new 32-bit depth texture format, as well as
an optimization called dual depth peeling which peels from the
front and from the back simultaneously.
- Render to 3D Texture (Whitepaper)
- This sample demonstrates the use of framebuffer objects to
render to a 3D texture. It does a simple wave simulation on the
3D texture, and displays it by ray marching
- Transform Feedback Fractal (Whitepaper)
- "Transform Feedback Fractal" shows an advanced use of the
transform feedback and the geometry shader, by iteratively
feeding the data through the transformation stages, adding more
detail each time.
- Simple Geometry Program (Whitepaper)
- Simple Geometry Program demonstrates the use of the assembly
level GL_NV_gpu_program4 shading extension, focusing on
geometry shaders.
- Cg Isosurf (Whitepaper)
- Cg Isosurf demonstrates the use of the geometry shader to
tessellate an isosurface using marching tetrahedrons. The
shaders includes tessellate metaballs, a texture volume, and a
procedural volume.
- Cg Geometry Program (Whitepaper)
- Cg Geometry Program demonstrates the use of Cg 2.0 in loading
and using geometry programs with OpenGL. The sample includes
programs for silhouette determination, curve tessellation, and
fin extrusion
- Samples from NVIDIA Graphics SDK 9.52:
- Coverage-Sampled Antialiasing (CSAA) Tutorial (Whitepaper)
- This sample demonstrates how to enable Coverage-Sampled
Antialiasing (CSAA) on GeForce 8 series GPUs in DX9.
- Antialiasing with Transparency (Whitepaper)
- This sample demonstrates the GeForce 7 Series per-primitive
super-sample and multi-sample modes for antialiasing primitives
with transparent fragments. The problem with using alphatest to
virtually simulate geometry is a hard edge that is produced
where the test occurs. The conventional solution for dealing
with this problem is to use alpha blending. Using a GeForce 7
Series GPU, you can enable super-sampling or multi-sampling
per-primitive, yielding much higher image quality along the
alpha tested edges.
- SLI Best Practices (Whitepaper)
- This code sample demonstrates the proper way to detect
SLI-configured systems, as well as how to achieve maximum
performance benefit from SLI.
- Post Procesing Effects with Anti-Aliasing
- This example demonstrates how to combine post-processing
effects with multisample antialiasing in OpenGL. Current
texture hardware is not capable of reading directly from a
multisampled buffer, so it is not possible to use
render-to-texture in this case. Instead, we render to the back
buffer, and then use glCopyTexImage to copy from the back
buffer to a texture. The copy performs the necessary
downsampling automatically. This example also shows how to use
the Transparency Antialiasing mode of the ARB multisample
extension to provide higher quality, order independent
transparency for geometry such as trees. This mode converts the
alpha value of the pixel into a 16-level (dithered) coverage
mask, which is logically ANDed with the raster-generated
coverage mask.
- DXSAS Sample Implementation 0.8 (User Guide)
- This running code sample demonstrates how to implement a
DirectX Semantics and Annotations (DXSAS) ScriptExecute parser
in an engine. Full support for the standard annotations and
semantics is provided. The user interface lets you apply
multiple scene and model effects simultaneously, so the you can
see hundreds of different effect combinations. All effect files
were developed using FX
Composer.
- Instancing (Whitepaper)
- This sample uses Microsoft's Direct3D9 Instancing Group to
render thousands of meshes on the screen with only a handful of
draw calls. This significantly reduces the CPU overhead of
submitting many separate draw calls and is a great technique
for rendering trees, rocks, grass, RTS units and other groups
of similar (but necessarily identical) objects.
- Pseudo Instancing in OpenGL (Whitepaper)
- This sample demonstrates a technique for speeding up the
rendering of instanced geometry with GLSL.
- Query Sample (User Guide)
- Shows how to check for availability and use of the various
query types supported in DirectX9. This sample queries for and
displays results for queries of type: event, occlusion,
timestamp, timestamp frequency, timestamp disjoint, and if
running with the debug runtime, resource and vertex stats.
- Simple Vertex Texture (Video)
- This simple example demonstrates the use of the
NV_vertex_program3 extension to perform texture look-ups in a
vertex program. It uses this feature to perform simple
displacement mapping. The example also shows how to implement
bilinear filtering of vertex texture fetches.
- Medical Image Reconstruction (Whitepaper)
- Fast Fourier Transforms (FFT) are used to reconstruct images
from medical scans. This sample presents an implementation of
FFTs on the GPU. This implementation automatically balances the
load between the vertex processor, the rasterizer, and the
fragment processor; it also uses several other novel techniques
to obtain high performance on the Quadro NV4x family of GPUs.
This technique is described in GPU Gems 2: Programming
Techniques for High-Performance Graphics and General-Purpose
Computation.
- Motion Blur as a 2D Post-Processing Effect (GDC 2003 Presentation)
- This example demonstrates motion blur as a 2D post process. The
algorithm was described at GDC 2003 in the "Stupid
OpenGL Shader Tricks" presentation. The advantage of this
method over an accumulation buffer is that you only need to
render the scene once, but it does have artifacts.
- Occlusion Query - OpenGL
- This sample illustrates occlusion query using a simple sphere and a plane.
- Occlusion Qery - DirectX (Whitepaper)
- This sample shows usage of occlusion queries to cull out
complex objects and save bandwidth to the card. Occlusion
queries report how many pixels a set of draw calls actually
wrote to.
- GPU Particles (Whitepaper by Lutz Latta)
- This sample implements a large-scale particle system entirely
on the GPU. The positions and velocities of each particle are
stored in floating point textures. Fragment programs are used
to update the velocities and positions of the particles by
rendering to texture each time step. The particles also collide
against a sphere object, and a terrain heightfield which is
stored in a texture. If available, the multiple draw buffers
extension (MRT) is used to update the position and velocities
in a single pass. The particles are rendered as point sprites.
The position texture is converted into a vertex array for
rendering the particles using the vertex buffer and pixel
buffer object extensions (VBO and PBO). On the GeForce 6800,
this method can render a million particles at about 20 frames
per second. This example is inspired by Lutz Latta's talk from
GDC 2004, "Building a
Million Particle System".
- Clip Planes (Whitepaper)
- This entrys shows various ways to clip a scene. It demonstrates
user clip planes as well as a technique to shear the near clip
plane to implement a single custom user clip plane(useful for
water planes)
- Depth Peeling 2
- This entry is a port of the original Depth Peeling ("layerz")
sdk sample, but it is much simpler, because it uses fragment programs
instead of complicated texture shaders.
- External Triangles
- This entry illustrates the strange things that happen when you
use homogeneous vertex positions. It has views that help you
see how a single triangle looks in screen space, world space,
and 2D homogeneous space.
- Raytraced Refraction
- This eyeball shader presents a method for adding high-quality
details to small objects using a single-bounce ray traced pass.
In this example, the polygonal surface is sampled and a
refraction vector is calculated. This vector is then
intersected with a plane that is defined as being perpendicular
to the object's X axis. The intersection point is calculated
and used as texture indices for a painted Iris.
- The sample permits varying the index of refraction, the depth
and density of the lens. Note that the choice of geometry is
arbitrary -- this entry is a sphere, but any polygonal model
can be used.
- Fog Comparison
- This effect demonstrates the GL_NV_fog_distance extension, and
compares the use of radial-distance-based fog to standard
depth-based fog. Standard fog computes fog values using just
the eye-space Z distance of each vertex. This extension
computes fog based on the actual Euclidian distance of the
vertex from the viewpoint, resulting in more realistic fog. Use
the 'f' key to cycle the fog mode from GL_LINEAR to GL_EXP and
GL_EXP2. The difference between radial distance fog and depth
fog is most evident in linear mode.
- Oblique Frustum Clipping
- This entry illustrates Oblique Frustum Clipping. This technique
is superior to using a user clip when rendering planar
reflections, such as a floor or water surface. Oblique Frustum
Clipping shears the near clip plane of the projection matrix to
match the water or floor surface, thus making it unnecessary to
use a separate clip plane. This saves much performance on cards
without native user clip plane support, such as GeForce4 and
lower, and some performance on cards with native user clip
planes, such as GeForceFX and higher.
- Order Independant Transparency 2
- This entry is a port of the original "oit" (order-independent
transparency) entry, but it is much simpler, because it uses
fragment programs instead of complicated texture shaders.
- Thinfilm
- This sample shows a thin film interference effect. Specular and
diffuse lighting are computed per-vertex in a GLSL vertex
shader, along with a view depth parameter, which is computed
using the view vector, surface normal, and the depth of the
thin film on the surface of the object. The view depth is then
perturbed in an ad-hoc manner per-fragment by the underlying
decal texture, and is then used to lookup into a 1D texture
containing the precomputed destructive interference for red /
green / blue wavelengths given a particular view depth. This
interference value is then used to modulate the specular
lighting component of the standard lighting equation.
- Cull Fragment Simple
- This sample illustrates using the cull fragment texture shader.
Automatic object space texture coordinate generation is used to
provide texture coordinates representing relative distance to
clipping planes. Based upon distance to the two planes, a
fragment is rejected or accepted for further processing. This
is similar to an alpha test but instead of using alpha, the
(s,t,r,q) texture coordinates determine if a fragment should be
eliminated from further processing. The texture shader program
used is very simple.
- Cull Fragement Complex
- This sample illustrates using the cull fragment texture shader
in conjunction with a vertex program to perform complex cull
fragment operations. In this example a vertex program is used
to compute custom texture coordinates representing distance
from a point (or minimum distance from a set of points). These
texture coordinates are then used to reject or accept a
fragment during rasterization. The vertex program is also used
to compute a simple diffuse lighting term.
- Depth of Field (Whitepaper)
- This entry shows render to texture, blurring an image by
repeated filter-blitting on the GPU, and generating a
depth-of-field effect.
- Volume Intersect
- This entry illustrates one way compute conservative shadow
bounds for improved stenciled shadow volume performance. It
computes a 3D screen space rectangle that can be used to
scissor and depth_bounds_test away updates to pixels that the
light will not affect.
- MeshMender Simple Example (User Guide)
- A simple example for NVMeshMender. NVMeshMender is a source
code library that prepares a model for per-pixel lighting by
generating a tangent basis (tangent, binormal, normal). It uses
smoothing groups to properly handle normal map texture
mirroring and cylindrical wrapping by splitting vertices that
can not, or should not, be smoothed together. It also gives
great control over what vectors can be smoothed together
through user-specified crease angles.
- From NVISION08:
- From NVISION08:
Want to Learn More?
NVIDIA Documentation Home Page
|
|
  |
